Primary Information

Secondary Name: Multi Cat
Vessel Type: Multi Cat
Classification: General Purpose Harbour Support Vessel
IMO: 1111111
MMSI: 503573600
Builder: Harwood Marine
Build Location: N/A
Year Built: 2011
Flag: Australian
Trading Area: N/A
Call Sign: N/A
Schematics (GA):


Length Overall: 15 Metres
Beam: 7 Metres
Design Draft: 1 Metres
Dead Weight: 0 Tonnes


Propulsion: Twin Fixed Pitch Propellers
Main Engines: 2 x CAT 3406 – 400hp each
Total Power: 800 hp KW
Gear Box: 2 x 3:1 Reduction
Generator: 100kw 3 phase

Speed and Consumption Performances

Full Operating Speed: 8.5 knots
Economic Operating: N/A
In Port: N/A
Bollard Pull: 8 ton (approx) Tonnes


Fuel: 11,600 Litres
Water: 200 Litres
Water Ballast: 4,400 Litres
Deck Load Rating: 5 Tonne/Sq. Metre

Deck Equipment

Anchor Handling Winch: 4 Tonnes
Crane: 5 Tonnes


Nautical and Communication Equipment

Radar System: Yes
GPS: Yes
Compass: Yes
Chart Plotter: Yes
AIS: Yes
VHF Radio: Yes
Searchlight(s): Yes

Miscellaneous Equipment

Description: Mooring System – 4 Point Anchoring

The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.

Charter enquiries can be directed to our Commercial Department
Phone: +61 8 9965 9700 Fax: +61 8 9965 4545 Email: commercial@bhagwanmarine.com

Specification ID: 0 Revision: 0
