Kougari
To view the Bhagwan Marine Group’s UK based Fleet, click here.
Primary Information
Secondary Name:
Vessel Type:
Classification: General Purpose Harbour Support Vessel
IMO: 1111111
MMSI: 503573600
Builder: Harwood Marine
Build Location: N/A
Year Built: 2011
Flag: Australian
Trading Area: N/A
Call Sign: N/A
Schematics (GA):
Dimensions
Length Overall: 15 Metres
Beam: 7 Metres
Design Draft: 1
Dead Weight: 0 Tonnes
Machinery
Propulsion: Twin Fixed Pitch Propellers
Main Engines: 2 x CAT 3406 – 400hp each
Total Power: 800 hp KW
Gear Box: 2 x 3:1 Reduction
Generator: 100kw 3 phase
Speed and Consumption Performances
Full Operating Speed: 8.5 knots
Economic Operating: N/A
In Port: N/A
Bollard Pull: 8 ton (approx) Tonnes
Capacities
Fuel: 11,600 Litres
Water: 200 Litres
Water Ballast: 4,400 Litres
Deck Load Rating: 5 Tonne/Sq. Metre
Deck Equipment
Anchor Handling Winch: 4 Tonnes
Crane: 5 Tonnes
Accommodation
Nautical and Communication Equipment
Radar System: Yes
GPS: Yes
Compass: Yes
Chart Plotter: Yes
AIS: Yes
VHF Radio: Yes
Searchlight(s): Yes
Miscellaneous Equipment
Description: Mooring System – 4 Point Anchoring
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.
Charter enquiries can be directed to our Commercial Department
Phone: +61 8 9965 9700 Fax: +61 8 9965 4545 Email: commercial@bhagwanmarine.com
Specification ID: 0 Revision: 0
