MDT 1501
General
Built: Singapore
Flag: Australian
Class: DNV
Main Dimensions
Length Overall: 43.89m
Beam Moulded: 15.24m
Depth Moulded: 3.05m
Draft (Max): 2.414m
Tonnage
GRT : 516T
NRT: 155T
DWT: 1200T
Deck Capacity: 5T/m²
Plating Scantlings
Deck: 10mm
Bottom: 10mm
Side: 10mm
Bulkhead: 10mm
No. of Bulkheads
Transverse: 5
Longitudinal: 1
No. of Stanchions
8 per side
Towing Bits
4 Smit Towing Brackets
The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.
Charter enquiries can be directed to our Commercial Department
Phone: +61 8 9965 9700 Fax: +61 8 9965 4545 Email: commercial@bhagwanmarine.com
Specification ID: 0 Revision: 0
