Primary Information

Secondary Name: Crew Transfer/Utilty Vessel
Vessel Type: Utility Vessel
Classification: DCV – USL 2B
MMSI: 503792800
Builder: Strategic Marine
Build Location: Singapore
Year Built: 2013
Flag: Australian
Trading Area: Offshore Operations up to 200 nm
Call Sign: VJN4337
M & H Number: 6928
No. Passengers/Special Personnel: 1B – 20 Pax, 2B – 12 Pax
No. Crew: 4


Length Overall: 24 Metres
Beam: 8.8 Metres
Depth Moulded: 3 Metres
Design Draft: 1.8 Metres
Dead Weight: 145 Tonnes


Propulsion: Twin Screw
Main Engines: 2x Yanmar 12 AYM-WST
Total Power: 1043 KW
Gear Box: Twin disc MGX 6690 SC
Generator: 2x 30 KVA

Speed and Consumption Performances

Full Operating Speed: 25 Knots @ 450 Lts/Hr
Economic Operating: 20 Knots @ 300 Lts/Hr
In Port: 100
Bollard Pull: 15 Tonnes


Fuel: 12,000 Litres
Water: 1,000 Litres
Sullage: 500 Litres
Clear Deck: 111 Metres Sq.
Max Deck Cargo: 40 Tonnes


Berths: 4

Nautical and Communication Equipment

Radar System: Furuno DRS-4A
Depth Sounder: Furuno FCV-585
DGPS: 2x Furuno GPS navigator GP-150
Compass: Autonautic Barcelona
Chart Plotter: Maxsea Time Zero
AIS: Furuno FA-50 AIS transponder
HF Radio: 1x Icom IC-M801E
VHF Radio: 2x Icom IC-M505
Sat Comms: Sailor 500 FleetBroadband sat comms, Furuno NAVTEX NX-700
Searchlight(s): 1x Den Haan type-350, 1000W

The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.

Charter enquiries can be directed to our Commercial Department
Phone: +61 8 9965 9700 Fax: +61 8 9965 4545 Email: commercial@bhagwanmarine.com

Specification ID: 0 Revision: 0
