Primary Information

Secondary Name: ASD Tug
Vessel Type: Tug
Classification: DCV – USL 2B
MMSI: 503484500
Builder: Elder-Prince Marine Services,
Build Location: Fremantle WA, Australia
Year Built: 1985
Flag: Australian
Trading Area: upto 200 nm
Call Sign: VM3470
M & H Number: 2559
No. Passengers/Special Personnel: 2
No. Crew: 4


Length Overall: 24.6 Metres
Beam: 8 Metres
Depth Moulded: 2.9 Metres
Design Draft: 1.7 Metres
GRT: 95 Tonnes
Dead Weight: 66 Tonnes


Propulsion: Azimuth thruster
Main Engines: 2x Caterpillar 3408
Total Power: 2x 283 KW
Gear Box: N/A
Generator: 2x Isuzu 6BG1 65kVa
Bowthruster: 1x Hydraulic

Speed and Consumption Performances

Full Operating Speed: 9kts
Economic Operating: 6kts
In Port: 250
Bollard Pull: 12t Tonnes


Fuel: 70,000 Litres
Water: 20,000 Litres

Deck Equipment

Tugger/Work Winch: 5 Tonnes


Berths: 8
Features: Fully Air Conditioned

Nautical and Communication Equipment

Radar System: Furuno M1835 with ARPA/AIS
Depth Sounder: Furuno SCV600C
GPS: GP7000 / GP32
Other: Auto Pilot – Navitron NTG888G

The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.

Charter enquiries can be directed to our Commercial Department
Phone: +61 8 9965 9700 Fax: +61 8 9965 4545 Email: commercial@bhagwanmarine.com

Specification ID: 0 Revision: 0
