Primary Information

Secondary Name: Tug
Vessel Type: Tug
Classification: 2B – 100 A5 TUG / MC
IMO: 9529554
MMSI: 503399200
Builder: Yong Choo Kui Shipyards,
Build Location: Malaysia,
Year Built: 2009
Flag: Australian
Trading Area: Offshore 200nm
Call Sign: VNW6293


Length Overall: 26 Metres
Beam: 8 Metres
Depth Moulded: 3.7 Metres
Design Draft: 3 Metres
GRT: 192 Tonnes
Dead Weight: 0.1 Tonnes


Propulsion: Twin Screw
Main Engines: 2x Yanmar 6a6AYM-ETE
Total Power: 2x 610kw @ 1900 rpm KW
Gear Box: 2x Reintjes WAF374. 6.417:1
Generator: 2x 80 kVa Cummins 6BT5.9-D (m)

Speed and Consumption Performances

Full Operating Speed: 9 Kts @ 100 Hr
Economic Operating: 7 Kts @ 85 Hr
In Port: 100 per day
Bollard Pull: 25t Tonnes


Fuel: 153,000 Litres
Water: 46,000 Litres
Sullage: 1,200 Litres
Water Ballast: 29,000 Litres
Lube Oil: 7,000 Litres
Dirty Oil: 7,000 Litres
Bilge Water: 7,000 Litres
Clear Deck: 20 Metres Sq.

Cargo Discharge Pumps

Fuel Cargo: 28M³/HR
Freshwater: 28M³/HR

Deck Equipment

Tow Winch: 20 Tonnes
Anchor Handling Winch: 2 Tonnes


Berths: 10
Features: Air-Conditioned, Galley/Mess & Sanitary Facilities

Nautical and Communication Equipment

Radar System: Furuno 1832
Depth Sounder: Furuno FCV 620
GPS: Furuno GP32
DGPS: Garmin GPS128
Compass: Daiko Keiki 150B
Chart Plotter: Furuno GD1920 C
AIS: Furuno FA50
HF Radio: Samyung SRG1150DN
VHF Radio: Gme GX600 & Horizon Quest GX1500S
GMDSS: Samyung SNX-300
Sat Comms: Furuno Felcom 15
Searchlight(s): Liang-Zhou TG27
Other: TMQ AP9

The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.
