Bhagwan Challenge

Primary Information

Secondary Name: Shallow Water Laybarge
Vessel Type: Flat Top Barge
Classification: ABS Deck Cargo
MMSI: N/A
Builder: P.T Batamas Jala Nusantara
Build Location: Tanjung Ucang, Batam
Year Built: 1996
Flag: Australian
Trading Area: within 200nm
Call Sign: N/A

Dimensions

Length Overall: 55 Metres
Beam: 21.3 Metres
Depth Moulded: 4 Metres
Design Draft: 0 Metres
GRT: 1226 Tonnes
Dead Weight: 3000 Tonnes

Machinery

Propulsion: N/A
Main Engines: N/A
Total Power: 0 KW
Gear Box: N/A
Generator: N/A

Speed and Consumption Performances

Full Operating Speed: 0
Economic Operating: 0
In Port: 0

Capacities

Fuel: Litres
Water: Litres
Deck Load Rating: 10 Tonne/Sq. Metre

Accommodation

Nautical and Communication Equipment

Miscellaneous Equipment

Description: 1996 General Purpose Barge, Designed And Built to ABS Rules for Building & Classing Steel Barges. Deck loading capacity: 10 ton/m² with increased capacity of 20ton/m² (in designated areas at the stern).

The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.

Charter enquiries can be directed to our Commercial Department
Phone: +61 8 9965 9700 Fax: +61 8 9965 4545 Email: commercial@bhagwanmarine.com

Specification ID: 0 Revision: 0
