Vessel Particulars

Class: DCV 2B
Flag: Australian
Official No Unique Identifier: 438374
Hull: Aluminium Monohull
Propulsion: Twin Screw
Berths: 12
Total Passengers: 12
Call Sign: VNW5970


Length Overall: 25.2m
Beam: 8.7m
Draft Design: 2.14m (Loaded)


Main Engines: 2 x Duetz Mwm Tbd 234 V12
Main Generators: 2 x Henkl WO4D
Total Power Kw: 2 x 38Kw @ 1500Rpm
Gear Box: 2 x ZF Bw 195 2.571:1


Full Operating: 18kts @ 300L/Hr
Eco Operating: 15Kts @ 225 L/Hr

Ship Capacities

Fuel: 28,000L
Water: 2,400L + Desal @ 2000L/Day


Deck Cargo: Approx 10T

Bridge Equipment

Chart Plotter: 1 x Maxsea
Depth Sounder: 1 x Furuno Ch18 Colour : 1 x Furuno Fcv581
Radar: 1 x Furuno (+ Spare)
GYRO: 1 x Tokyo Keiki
Auto Pilot: 1 x Tokyo Keiki
Email: wauri@bhagwanmarine.com

Deck Equipment

Crane: 5.6Kn @ 5.0m – Swl 570kg @ 5.0m : 9.22kn @ 3.0m – Swl 940 @ 3.0m

Safety Equipment

Rescue Zones: Port & Starboard

Additional Details

Features: 1 x Medivac Stretcher
Twin Keels
Towing Bollards – 80.44Kn
Deck Lashing Lugs – 19.62Kn
Fendering on sides
8.5m Open Transom
Sanitary Facilities & Laundry
Fully Acir Conditioned

The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.
